Wire buckles, Seals and Corner Protectors

Wire Buckles
Copyright© PUTO s.r.o.    |    Tvorba web stránok
tvorba web stránok
Product ID Applicable strapping Width of the applicable strapping Pieces per package Coating
SD 13 40 PW
40 PSAW		 13 mm 1000 zinc-coated / phosphate-coated
SD 16 50 PW
50 PSAW		 16 mm 1000 zinc-coated / phosphate-coated
SD 19 60 PW
60 PSAW
65 PSAW		 19 mm 1000 zinc-coated / phosphate-coated
SD 25 90 PSAW
95 PSAW		 25 mm 500 zinc-coated / phosphate-coated
SD 32 105 PSAW 32 mm 100 zinc-coated / phosphate-coated
SD 36 200 PSAW 36 mm 100 zinc-coated / phosphate-coated
Seals
Product ID Size Applicable strapping Width of the applicable strapping Pieces per package
SP 10 10 - 28 - 0,5 PP            9-10 mm 1000
SP 12 13 - 28 - 0,5 PP 12 mm 2500
SP 16 16 - 28 - 0,5 PP 15-16 mm 1600
SP 19 19 - 28 - 0,6 PP 19 mm 1300
SP-O-12 13 - 30 - 0,8 PP/PET 12 mm 1600
SP-O-16 16 - 30 - 0,8 PP/PET 15-16 mm 1000
SP 10 - 19
SP - O - 12 - 16
Corner Protectors
• provide better protection for easily deformable materials
• margin guides prevent strap slipping

Edge Protectors
• provide better protection for easily deformable materials
• increase load strength and stability
• also usable as a box reinforcement
Product ID Applicable strapping Pieces per package Material
R- PP PP 1000 polypropylene
R- PA PSAW / PET 1000 polyamide
R- KA PSAW / PET 1000 carton
H- KA PSAW / PET 25 carton
phosphate-coated
Edge protector- carton
Edge protector- polypropylene
Edge protector-polyamide
Plastic Clips
Product ID Applicable strapping Width of the applicable strapping Pieces per package
SPL12 PP 12 mm 1000
SPL16 PP 16 mm 1000
Plastic clip
• used with woven polyester (PSAW) strapping
• self-lock mechanism (they firmly lock when tightened by a tensioner)
• the joint of a wire buckle and PSAW strapping is retensionable
• offered in two variants of surface adjustment:
                     - zinc-coated (smooth, bright) - standard adjustment, providing a longer lasting protection from                          corrosion
                     - phosphate-coated (rough, matt) - buckles with an advanced anti-sliding adjustment which
                       increases the joint firmness by 15%
• used with polypropylene (PP) or extruded polyester (PET) strapping
• one-shot usage - they form a solid, undetachable joint
• used with polypropylene (PP) strapping
• applicable if wire buckles or seals are inappropriate (due to recykling)
• self-locking, enabling additional fastening
• eligible for repeated use
